EPFU 2V 9/125 SM G657A1
Fiber Unit (FU) with 2 fibers in an encapsulation layer providing excellent dimensional and thermal stability. An outer thermoplastic layer provides a high level of protection and excellent installation properties. The FU is designed for blowing into microducts and tube bundles. The fibres are dry, not coated with gel, thus permitting fast and contamination –free connections.
Specifications:
Number of fibers: 2
Fiber type: G657A1
Fiber colors: blue, green
Outer sheath color: yellow
Cable outer diameter: 1,12mm
Weight: 0,9kg/km
Fibrepan: 2, 4, 6 or 12km
Fiber Unit (FU) with 2 fibers in an encapsulation layer providing excellent dimensional and thermal stability. An outer thermoplastic layer provides a high level of protection and excellent installation properties. The FU is designed for blowing into microducts and tube bundles. The fibres are dry, not coated with gel, thus permitting fast and contamination –free connections.
Specifications:
Number of fibers: 2
Fiber type: G657A1
Fiber colors: blue, green
Outer sheath color: yellow
Cable outer diameter: 1,12mm
Weight: 0,9kg/km
Fibrepan: 2, 4, 6 or 12km
| Outer diameter | 1.12 | Outer jacket colour | yellow |
|---|---|---|---|
| Fibre type | G657A1 | Fibre amount | 2 |
